2026/2027 KODIAK 450

SPECIFICATIONS

ENGINE Engine Type: 421cc liquid-cooled SOHC 4-stroke; 2 valves Bore x Stroke: 84.5mm x 75.0mm Compression Ratio: 10.0:1 Fuel Delivery: Yamaha Fuel Injection (YFI), 34mm Transmission: Ultramatic V-belt with all-wheel engine braking; H, L, N, R, P Final Drive: On-Command selectable 2WD or 4WD; shaft Fuel Capacity: 3.7 gal

CHASSIS Suspension/Front: Independent double wishbone; 6.7-in travel Suspension/Rear: Independent double wishbone; 7.4-in travel Brakes/Front: Dual hydraulic disc Brakes/Rear: Multi-disk wet brake Tires/Front: AT25 x 8-12 Tires/Rear: AT25 x 10-12

DIMENSIONS LxWxH: 80.1 in x 46.5 in x 45.7 in Seat Height: 33.7 in Wheelbase: 48.8 in Max. Ground Clearance: 9.6 in Fuel Capacity: 3.7 gal Wet Weight: 637 lb

KEY FEATURES

POWERTRAIN 421cc Engine: The torquey 421cc SOHC engine delivers a well-balanced combination of responsive power and smooth character. Vibration-Reducing Engine Mounts: Specifically developed rubber engine mounts isolate engine bay vibrations for an ultra-smooth ride experience. Mikuni Fuel Injection: Mikuni fuel injection ensures easy cold starts and flawless fuel delivery in various conditions. Cool Performance: Liquid-cooling and a high-volume fan system provide reliable and consistent performance. High-Mounted Air Intake: High-mounted air intake design provides added power and torque while shielding against water, mud, and trail debris. Reusable Foam Air Filter: Reusable foam air filter is accessible without tools for simple maintenance. Ultramatic CVT Drive System: Yamaha’s Ultramatic Drivetrain is the industry’s most advanced and durable CVT drive system. Ultramatic Gears: The Ultramatic Drivetrain features a gated shifter with park, dual-range Hi/Lo drive, and a reverse gear. Centrifugal Wet Clutch Belt Drive: Ultramatic CVT system combines a centrifugal wet clutch with a constant-tension belt system for excellent reliability. Sprag Clutch Engine Braking: A one-way sprag clutch adds confidence with predictable all-wheel engine braking at all speeds. 10-Year Belt Warranty: Yamaha’s Ultramatic CVT is backed by an industry-exclusive 10-Year Belt Warranty. Separate Drive System Air Intake: Separate high-mount drive system air intake regulates temperature and helps keep water and debris out of the drive case. On-Command 4WD: On-Command 4WD system lets you switch between 2WD and limited-slip 4WD at the press of a button.

CHASSIS Compact Chassis: The Kodiak 450 is built with a compact chassis for precise handling and trail maneuverability. Roomy Ergonomics: Enjoy roomy ergonomics with a long plush seat, wide floorboards, and comfortable handlebar positioning for long days on the trail. Impressive Ground Clearance: The Kodiak 450 offers 9.6 inches of ground clearance to handle tough off-road terrain. Independent Double Wishbone Suspension: Independent double wishbone suspension with adjustable shocks deliver exceptional feel with an optimized stance. Off-Road Suspension: The Kodiak 450 is confident in rough terrain with 6.7 inches of wheel travel in front and 7.4 inches in the rear. Rugged Off-Road Tires: 25-inch tires feature an aggressive tread pattern for precision steering and optimized comfort. Rear Brake System: Four-wheel hydraulic disc brakes combined with a sealed wet rear brake system provide strong and consistent stopping power. Composite Skid Plates: Full-length composite skid plates provide excellent protection against rocks and obstacles. Steel Cargo Racks: Tough steel cargo racks with durable wrinkle paint can carry a combined 264 pounds. 2-Inch Receiver Built to Tow: A heavy-duty 2-inch receiver comes standard on the Kodiak 450 with a 1,322-pound tow rating. Marine-Grade Water Resistant Connectors: Marine-grade water resistant connectors maximize weather-proofing for Proven Off-Road durability and serviceability.

ADDITIONAL FEATURES LCD Instrument Cluster: A compact LCD instrument cluster provides a clear view of rider data including speed, transmission status, fuel level, and more. Handlebar Mounted Work Light: A handlebar-mounted halogen work light adds illumination that tracks with rider steering for added flexibility and excellent visibility. Injection Molded Fenders: Injection-molded fenders and CV joint guards shield against damage from rocks and debris. 12V Power Outlet: A convenient 12V power outlet keeps devices charged on the go. Yamaha Genuine Accessories: A range of Yamaha Genuine Accessories provides performance, convenience, protection, and styling options. Winch Pre-Wiring: Pre-installed wiring for a WARN winch enables easy installation for added confidence. Under Seat Storage: Under-seat storage secures your gear while out on the trail.
